Features
-
Crosshead position accuracy is better than 20µm (0.0008 in)
-
Two column heights and travels:
-
Standard Travel 20” (508mm)
-
Extended Travel 30” (762mm)
-
-
Three force capacities:
-
110 lbf (500N)
-
330 lbf (1500N)
-
550 lbf (2500N)
-
-
Reference distance travel ruler
-
Cycle for 99,999 counts or seconds (72 hours)
-
Hold at load or duration for up to seconds (72 hours)
-
Compact design is ideal for small work space and for lean manufacturing environments
-
Adjustable base adapter ensures correct sample alignment
-
Standard metric base with M4, M6, M10 and M12 threads
-
Optional imperial base with #10-32, 5/16-18, 1/4-28 and 1/2-20 threads
-
USB 2.0 and RS-232 Communications
-
Configurable crosshead speeds from:
-
0.002 to 40 in/min
-
0.05 to 1000 mm/min
-
-
Crosshead speed accuracy is better than 0.1% at full speed, full load
-
Adjustable, magnetic travel limits
-
Quiet operating even at full speed, full load
-
Easily upgrade from force gage control to computer-based operation using L1 software and 2-in-1 tablet PC
-
Two mounting blocks for:
-
Force gage mounting
-
BLC load cell mounting
-
-
Four configurable 0-24Vdc digital I/O channels for switch testing or use with annunciators and status lamps
-
Base clevis adapter kit supplied standard
-
Cast-aluminum base with bench clips to secure to work space if needed
-
Easy-to-use jog keys with excellent tactile feedback
-
Speed selection dial with high resolution display
